Simes s 6622 14 microloft wall 1led 3w 6000k220/240v gray

S.6622

Round Microloft

-TYPE

Wall-mounted device.

Degree of protection IP 65

-FEATURES OF THE MATERIALS

Body in extruded primary aluminium EN AW-6060 and die-cast EN

AB-47100 with high oxidation resistance.

Tumbling process to prepare for the painting phase.

Screws in A4 stainless steel with a high molybdenum content of 2.5-3%.

Silicone ricotta gaskets.

Extra-resistant double painting carried out in 3 phases:

1) BONDERITE treatment with chemical protection of the material

metal-free fluozirconium containing ceramic nanoparticles that

create a cohesive, inorganic, high-density layer.

2) PRE-POLYMERIZATION cycle with application of the primer

epoxy with characteristics of overpaintable on the appliance and of

high resistance to oxidation thanks to the presence of zinc.

3) POLYMERIZATION cycle with the application of polyester powder

with high resistance to UV rays and atmospheric agents,

with salt spray test resistance of 1500h.

Mechanical resistance of glass IK 06

-LIGHTING PERFORMANCE

Optical reflector in 99.98% pure aluminum, turned, anodized and polished.

Clear tempered protective glass.

Light source, with fixed lamp position.

Yield --

-INSTALLATION AND MAINTENANCE

Microloft H07RN-F resin-coated and pre-wired cable.

Miniloft and Loft with pre-wired base and freezer facilitate and

They make installation and maintenance operations safe.

-WIRING

Single entry for power cables.

Insulation Class: Class II

Available colors: WHITE (code 01), ALUMINUM GREY (code 14)

Weight: 0.97 kg

Glow wire test: --

Fixtures supplied complete with LED circuit with emission class

2 (CEI EN 60825-1: 2003-02)
